Product Name: China Complete Veneer and Shuttering Plywood Making Machinery /veneer production line /press machinery for sale
Major Technical Parameters:
|
DESCRIPTION |
UNIT |
BQ1813/G6GS-JD
General |
|
Length of log |
mm |
900-1400 |
|
Diameter of log |
mm |
Φ30-Φ650 |
|
Length of blade |
mm |
1500 |
|
Thickness of veneer |
mm |
0.8-4.0 |
|
Width of cut veneer |
mm |
500-1300 |
|
Linear speed of host machine |
m/min |
42~80m/min
|
|
Diameter of driving roller |
mm |
115 |
|
Diameter of pressurebar roller |
mm |
116 |
|
Diameter of rubber roller |
mm |
140 |
|
Power ofpressurebar roller |
KW |
15 |
|
Power of doubleroller |
KW |
15 |
|
Power of cutting feed |
KW |
15 |
|
Power of shear |
KW |
3 |
|
Power of PU roller/ output converyor |
KW |
1.5 |
|
Total power |
KW |
49.5 |
|
Total weight |
kg |
6500 |
|
Overall dimensions |
mm |
3700*2800*1700 |
Main Features:
1.Log veneer peeling and cutting all in one.
2. Simple operation & easy maintenance ; the quality of wood veneer thickness similar to that of veneer peeled by the spindle rotary peeling machine.
3. Upgraded technology guarantee the flatness, evenness and smoothness of different thickness veneer
4. Special self-made drive reducer according to the structure and speed of Spindleless veneer peeling machine
